Rain Water Steel Down Pipe Roll Forming Machine 333

Place of Origin : Botou Hebei China

Brand Name : HC

Certification : CE

Model Number : HC100

MOQ : 1set

Packaging Details : Main machine is nude,the computer control box is packed by carton box.

Delivery Time : 30days

Payment Terms : T/T,L/C

Supply Ability : 20 sets/month

Type : Rain Water Steel Down Pipe Roll Forming Machine

Material : DX52/DX53

Width : 333mm

Contact Now

Rain Water Steel Down Pipe Roll Forming Machine

Our Rain Water Steel Down Pipe Roll Forming Machine can produce various of steel roof and wall panel, it is a new building materials, the products are widely used as the roof and wall of factory, warehouse, garage, gymnasium, exhibition center, cinema, theatre, etc. It has many advantages, such as easy installation, short building period, beauty, light weight but high strength.

SPECIFICATIONS FOR Rain Water Steel Down Pipe Roll Forming Machine
Main Roll Forming Machine	Roller station	18 rows
	Material of roller	High grade 45# forged steel plated with hard chrome plating
	Material of cutter	Cr12 mould steel with quenched treatment
Material	Type	PPGI GI AL
	Material width	customized
	Material thickness	0.3-0.6mm
Others	Speed	10m/min
	PLC system	DELTA
	Weight	7.2T

Rain Water Steel Down Pipe Roll Forming Machine Features

We do high standard roll forming machine for export about 18 years.
We have mature foreign trade team,senior engineers, experienced workers to make you satisfied.
We have machines at more than 130 cuntries and regions,and keep good business relationship.
we offer one year free warranty and free service for whole life of any machine.

Certifications

Rain Water Steel Down Pipe Roll Forming Machine 333

Metal Roofing Sheet Roll Forming Machine Parts

Detailed Images

Rain Water Steel Down Pipe Roll Forming Machine 333

Name: Rollers
In order to get high quality product, our machine adopts welded steel frame structure, AC frequency conversion motor reducer drive, chain transmission, roller surfaces polishing, hard plating, heat treatment and chrome coating.
Roller chrome coated.
Roller material: Forging Steel 45# heat treatment

Main Roll Former We have experieced workers to design the rollers as customized profile drawing , and adopts welded steel frame sturcture, AC frequency conversion motor reducer drive, chain transmission , to get strong machine for good finish products .
	Hydraulic Cutting System It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products. With non stop cutting Material of blades: Cr12,quenching treatment

Our Service


Pre-Sales Service * Inquiry and consulting support. * Sample testing support. * View our Factory.	After-Sales Service * Training how to instal the machine, training how to operate the machine. * Engineers available to service machinery overseas.

Packing & Delivery

Size: 12000 (L) * 1500 (W) * 1510 (H)
Weight: 4.5T
1.Main Roll Forming Machine and un-coiler is nude packing (If you need, we can also packed it with water-proof plastic)
2. PLC control system and motor pump are packed with water proof paper,spare parts in carton box.
3.One set of machine needs a 40' container to shipping.
